    High Efficiency Soy Protein Pressure Granulator Dryer SUS316 Spray Drying Machine

    Ask Lasest Price
    Brand Name : WKS
    Model Number : YPG-50
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 10 SETS PER MONTH
    Delivery Time : about 30 working days
    • Product Details
    • Company Profile

    High Efficiency Soy Protein Pressure Granulator Dryer SUS316 Spray Drying Machine

    High Efficiency Soy Protein Pressure Spray Granulator Dryer Drying Machine


    Pressure Spray Dryer


    YPG Pressure Spray Dryer Description

    YPG pressure spray dryer is suitable for solution, suspension, slurry, paste material, etc. Liquid material is atomized to small fog drops. And fog drops contact with hot air directly in the drying tower. Moisture content is evaporated instantly. So spray dryer features high efficiency, high mass transfer area, and short drying time, in general it is 5~30 seconds. Operating temperature can be adjusted according to actual situation, in general inlet air temperature is 150~500°C. And its automation control degree is control, environment solution environment can be solved.


    Technical parameters

    ModelYPG-25YPG-50YPG-100YPG-150YPG-200YPG-300YPG-500YPG-1000-2000
    Water evaporation kg/h2550100150200300500The index can be affirmed inaccordance with particle conditions.
    DiaphragmPumpPower kW0.3547.511152230
    Pressure Mpalt can be regulated from 0.6-5, usually, it is between 1-3 when in operation
    Heating wayElectricityElectricity+steamElectricity+coal(oil) hot air furnace
    Diameter of tower mm1300180024002600280032003800
    Total height of equipment mm780092001160014000153001710019000

    High Efficiency Soy Protein Pressure Granulator Dryer SUS316 Spray Drying Machine

    YPG Pressure Spray Dryer Application
    Foodstuff industry: Amino acid and similar substance, flavoring, protein, starch, dairy products, instant coffee, fish powder, meat powder, tomato paste and so on.
    Pharmaceutical Industry: Chinese patent medicine, agrochemical, antibiotics, medical drinking agent and so on.
    Chemical industry: Organic catalyst, resin, synthetic washing powder, thiamin, dyestuff, intermediate of dyestuff, intermediate of dyestuff, white carbon black, graphite, ammonium phosphate and so on.
    Ceramic industry: Magnesium oxide, kaolin, metallic oxide, dolomite and so on.


    YPG Pressure Spray Dryer Features
    1. The machine has high efficiency to collect dust
    2. Without the phenomenon of adhering wall
    3. Energy saving and high efficiency
    4. Particularly it is suitable for thermal sensitive material
    5. Short drying time
